ATID – AT907
AT907 is a versatile and reliable device that is developed in combination with the needs of IOT application scenarios. It compact in size and has a long battery life, and high-performance antenna. It equipped with a variety of software and connectivity options, allowing it to be easily integrated with existing systems and workflows. The AT907 by ATID stands as a pinnacle in RFID technology, designed to elevate your tracking and identification processes to unprecedented levels of efficiency and accuracy. This handheld RFID reader empowers businesses across diverse sectors with its advanced capabilities and user-friendly interface. With its compact yet robust design, the AT907 is your indispensable tool for streamlined operations and enhanced productivity.
Specification
Benefits
With a read range of up to 10 meters, the AT907 swiftly captures RFID data, minimizing time spent on manual tracking. This rapid data collection translates to increased operational efficiency and reduced labor costs.
Equipped with a powerful ARM Cortex-A53 Quad-Core processor and ample memory, the AT907 effortlessly handles intensive RFID tasks with speed and precision. Its reliable performance ensures uninterrupted operation even in demanding environments.
Featuring a 5-inch HD LCD with Capacitive Touchscreen, the AT907 offers a seamless and intuitive user interface. Its Android 8.1 operating system enables smooth navigation and compatibility with a wide range of applications, simplifying deployment and integration.
Related Products
The UHF near-field antenna ID ANT.U82/82 is a compact and high-performance antenna that is ideal for use in enclosed spaces. With its small form factor and defined near-field reading area, it can be installed almost anywhere. It operates in a wide frequency range of 864-928 MHz, making it suitable for worldwide use.
- Dimensions: 82 mm x 82 mm x 9.5 mm
- Weight: approximately 50 g
- Housing: ABS material
- Color: anthracite
- Max. input power: 1 W
- Antenna connector: SMA (female)
- Anti-static Protection/Antenna Detection: 60 Ohm DC Resistance (typical)
- Operating frequencies: 864 MHz up to 928 MHz
- Temperature range:
- Operation: 0degree C up to +50degree C
- Storage:-30degree C up to +60degree C
The ID ANT40/30 and ID ANT100/100 are HF antennas designed for RFID proximity readers. They have an impedance of 50 ohm and operate at a frequency of 13.56 MHz. The antennas have a maximum transmitting power of 1 W and a data transfer rate of up to 424 kbits/s. The ID ANT100/100 has a reading distance of up to 14 cm. These antennas are suitable for applications such as eTicketing, eMobility, and Closed Loop Payment.
- Dimensions: ID ANT40/30 – 40 mm x 30 mm, ID ANT100/100 – 100 mm x 100 mm
- Interface: 2-pin connector or U.FL connector option
- Operating frequency: 13.56 MHz
- Impedance: 50 ohm
- Max. transmitting power: 1 W
- Max. reading distance: ID ANT40/30 – up to 7 cm, ID ANT100/100 – up to 14 cm
- Data transfer rate: ID ANT40/30 – up to 424 kbit/s, ID ANT100/100 – up to 212 kbit/s
- Power supply: Unneeded
- Temperature range: Operation -25 degree C up to +70 degree C, Storage -40degree C up to +85 degree C
- Relative air humidity: 0% up to 95% (non-condensing)
The ID MAT Manual Antenna Tuner is a versatile and reliable device designed for manual tuning and retuning of HF Long Range Antennas operating at a frequency of 13.56 MHz. It allows for easy construction of customized single antennas using different sizes and shapes of antenna conductors such as aluminium bands or copper pipes. With individually switchable capacitors, the antenna can be tuned to its environment, ensuring optimal performance. The ID MAT.S-A variant also features an electronic switch to disconnect the antenna circuit, preventing coupling effects in complex antenna arrangements.
- Dimensions (w x h x d):
- ID MAT-B: 90 mm x 45 mm x 17 mm
2. ID MAT.S-A: 90 mm x 45 mm x 19 mm - Weight: approximately 35 g
- Operating frequency: 13.56 MHz
- Antenna conductor: Double-sided solder surface with hole for screw attachment (M3)
- Transmitting power: maximum 8 W
- Reader connection: SMA HF socket RG58
- Impedance: 50 ohm
- Tuning range inductivity: 0.6 – 2.3 microH
- Quality: 10 – 50
- Temperature range:
- Operation: -25 degree C up to +55 degree C
- Storage: -25 degree C up to +60 degree C
- Standard conformity:
- Vibration: EN 60068-2-6, 10 Hz to 150 Hz: 0.075 mm / 1 g
2. Shock: EN 60068-2-27, Acceleration: 30 g
The Dynamic Antenna Tuner ID DAT is a versatile device designed for automatic tuning and retuning of RFID Long Range Antennas operating at 13.56 MHz. With its easy “Plug & Play” functionality, it eliminates the need for additional tuning devices. The tuner can be driven via HF connection and allows for parameters or calibration status to be sent to the host. It also features an electronic switch to disconnect the antenna circuit when necessary.
- Dimensions: 118 mm x 90 mm x 19 mm
- Weight: approximately 100 g
- Operating frequency: 13.56 MHz
- Supply voltage: 7 – 12 V DC
- Current consumption: maximum 150 mA (DC)
- Transmitting power: maximum 10 W
- Antenna switch: electronic switch (mind maximum antenna power!)
- Antenna connection: cable terminals (d = 2 – 9 mm)
- Reader connection: SMA socket (50 ohm)
- Triggering reader: via RF connection
- Signal indicator: 1 x “Run”-LED (green), 2 x “Protocol”-LED (red)
- Outputs: 3 x open collector: 5 V DC / maximum 15 mA
- Carrier frequency: 13.56 MHz
- Impedance: 50 ohm
- Tuning range inductivity: 0.7 – 2.5 microH
- Quality: 10 – 50
- Temperature range:
- Operation: -25 degree C up to +75 degree C
- Storage: -40 degree C up to +85 degree C
The 4 Channel Antenna Multiplexer (ID CPR.ANT.MUX-M4) is a device that allows the connection of up to 4 external antennas to the reader module ID CPR74. With this multiplexer, it is possible to create up to 5 reading areas by utilizing the internal antenna of the ID CPR74. The control of each active antenna can be easily configured through the CPR74 or via two digital inputs with external control electronics. The multiplexer features non-wearing electronic switching of the outputs and has a high switching speed of less than 1 ms.
- Weight: 12 g
- MTBF (Mean Time Between Failures): 500,000 hours
- Power supply: +5 V DC ± 5%
- Current consumption: Less than 40 mA
- Digital inputs: Low level: 0 -0 V, High level: 3.8 V – VCC, Pull-Down: 10 kohm
- LED: 4 yellow LEDs for indicating active antennas
- Operating frequency: 13.56 MHz
- RF power: Maximum 500 mW
- Reader connection: U.FL connector
- Antenna connection: 4 x U.FL connectors for external antennas
- Temperature range: Operation: -25 degree C up to +70 degree C, Storage: -40degree C up to +85 degree C
- Relative air humidity: Maximum 95% (non-condensing)
- Standard conformity: EMC: EN 301 489, Safety & Health: EN 62368-1, EN 50364, Environment: WEEE-2002/96/EC, RoHS-2011/65/EC
The UHF Antenna Multiplexer from FEIG is a versatile solution for connecting and controlling multiple antennas with a single reader. It allows for easy installation and communication via the antenna cable, eliminating the need for additional control lines. With a high switching speed and the ability to cascade up to three levels, this multiplexer is ideal for applications that require many small reading points in a confined space, such as smart shelves and logistics systems.
- Dimensions: 85 mm x 145 mm x 27 mm
- Weight: 170 g
- Housing: Plastic ABS
- Color: Black, transparent
- Protection class: IP30
- Operating frequency: 860 MHz to 960 MHz
- Supply voltage: 12 V DC to 24 V DC ±10%
- Power consumption: Max. 200 mA
- Insertion loss: Max. 2.2 dB
- Isolation: Min. 28 dB
- Input power: Max. 4 W
- RF-Connector: 1x Reader input (SMA-Female), 8x Antenna output (SMA-Female)
- DC-Coupling: -7 V / 150 mA, -12 V DC to 24 V DC / 150 mA
- Indicator, optical: 4 LEDs (Diagnostic, operating state), 8 LEDs (Indication of active antenna output)
- Temperature range: Operation: -25 degree C up to +55 degree C, Storage: -25 degree C up to +85 degree C
- Standard conformity: EMC (EN 301 489-3), Safety & Health (EN 62368-1, EN 50364)
