Beontag – Casey
The Beontag Casey is a disposable high-performing label designed for supply chain and logistics applications. It utilizes UHF RFID technology with EPCglobal Gen2v2 compatibility. With an operational frequency of 865-928MHz, it offers a read range of up to 18m/60ft on both plastic and cardboard surfaces. The label features an Impinj® M730 IC chip with EPC 128bit and TID 96bit memory configuration. It is resistant to water (IP68) and various chemicals, including sulfuric acid, motor oil, saltwater, NaOH, and acetone.
The label is lightweight (0.6g) and comes in a delivery format of 2000 pcs on a reel. It has a tag dimension of 92 x 24 x 0.2mm and can withstand operating temperatures ranging from -35degree C to +85degree C. The Beontag Casey label offers reliable performance, durability, and customization options for efficient tracking and identification in diverse environments.
Specification
Benefits
The Beontag Casey™ label utilizes UHF RFID technology to provide accurate and efficient tracking of items in supply chain and logistics applications, ensuring visibility and traceability throughout the process.
With its IP68 water resistance and resistance to various chemicals, including sulfuric acid, motor oil, saltwater, NaOH, and acetone, the Beontag Casey™ label offers reliable performance even in challenging environments, ensuring the longevity of the label and the information it carries.
The Beontag Casey™ label offers personalization options such as pre-encoding and customized printing, allowing customers to tailor the label to their specific needs, including encoding of EPC or user memory, locking permanently or with a password, and incorporating logos, text, numbers, barcodes, and more.
