Beontag – Ferrowave Micro Global
The Beontag Ferrowave Micro Global is a compact, printable RAIN RFID label engineered for optimal performance on metal surfaces and resilience in harsh industrial conditions. With read ranges up to 4 meters on metal and high chemical and temperature resistance, it is ideal for applications such as automotive manufacturing, industrial asset tracking, and maintenance processes. Its small footprint and flexibility allow it to be applied even to slightly curved surfaces, making it a versatile choice for challenging tagging scenarios.
Specification
RFID & IC Options:
-
Type: RAIN RFID / EPCglobal Gen2v2
-
Frequency: 865–928 MHz (global)
-
IC Options:
-
Impinj® M730 – EPC 128b, TID 96b
-
Impinj® M780 – EPC 496b, User 128b, TID 96b
-
-
Read Range (2W ERP):
-
On metal: up to 4 m / 13 ft
-
On liquid: up to 3 m / 10 ft
-
On plastic: up to 1.5 m / 5 ft
-
On cardboard: up to 1.2 m / 4 ft
-
-
Surface Compatibility: All surfaces, optimized for metal
Mechanical:
-
Dimensions: 45 × 8 × 1.5 mm (1.77 × 0.31 × 0.06”)
-
Label Surface: Printable white PET (resin ribbon recommended)
-
Adhesive: Acrylic, optimized for metal and painted metal
-
Weight: 0.25 g
-
Delivery Format: 800 pcs/reel, defective labels marked
Environmental:
-
Operating Temperature: –35 °C to +85 °C
-
IP Rating: IP68 (5 hrs in 1 m water)
-
Chemical Resistance: Resistant to salt water, NaOH, motor oil, and sulfuric acid (168h exposure)
-
Washing Resistance: Suitable for industrial washing cycles
-
Storage: 1 year at +20 °C / 50% RH
Mounting Recommendations:
-
Clean and dry surface before application
-
Avoid touching adhesive and IC
-
Ideal application temperature: +21 °C to +38 °C
-
Works on slightly curved surfaces; optimal mounting orientation recommended for best performance
Order Information:
-
3003658 – Ferrowave Micro M730
-
3004218 – Ferrowave Micro M780
Benefits
Engineered for strong on-metal read performance with compact size for space-limited applications.
Withstands extreme temperatures, chemical exposure, and IP68 water protection for reliable operation in harsh environments.
Supports on-demand printing with durable PET face, enabling easy customization and integration into labeling workflows.
