Zebra – FXR90 Ultra-Rugged Fixed RFID Reader
The FXR90 Ultra-Rugged Fixed RFID Reader is designed to thrive in the harshest environments, offering unmatched durability and performance. Engineered for transportation, logistics, warehousing, and manufacturing settings, it withstands extreme weather, dust, and moisture infiltration. With a robust read rate of over 1,300 tags per second and advanced connectivity options, including Wi-Fi 6, Bluetooth 5.3, 5G, GPS, and CBRS, the FXR90 ensures reliable, real-time data capture. The reader features an integrated RFID antenna for simplified deployment and versatile power options, including PoE, making it ideal for both indoor and outdoor applications. Zebra’s FXR90 is built to deliver high performance and reliability, helping businesses enhance asset tracking and operational efficiency.
Specification
- Dimensions:
- Without integrated RFID antenna: 13.2 x 10.0 x 2.2 in (with flush mount brackets)
- With integrated RFID antenna: 13.2 x 10.0 x 2.9 in (with flush mount brackets)
- Weight:
- Reader only: 5.95 lbs (with flush mount bracket)
- Integrated antenna model: 6.75 lbs (with flush mount bracket)
- Housing Material: Diecast aluminum (reader body), polycarbonate/polybutylene terephthalate blend (antenna radomes)
- Visual Status Indicators: Power, Activity, Status, Application, Ethernet, Bluetooth, Wi-Fi, Cellular
- Operating System: Linux
- Memory: 2GB LPDDR4 RAM/16GB eMMC Flash
- Maximum RFID Read Rate: 1,300+ tags/sec
- Maximum RFID Read Range: 100 ft (30.5 m)
- Nominal RFID Read Range: 55 ft (16.7 m)
- Integrated Antenna Gain: 7 dBi
- Wireless LAN: IEEE 802.11ax/ac/a/b/g/n 2X2, MU-MIMO
- Bluetooth: Class 1, Bluetooth v5.3 with BLE
- Operating Temperature: -40F to 149F (-40degree C to 65degree C)
- IP Sealing: IP65 and IP67
- Power Supply Options: Direct 12 VDC to 24 VDC, Zebra AC/DC IP67 Sealed Power Supply, Power-over-Ethernet+ Injector (802.3at)
- Certifications: UL 62368-1, IEC 62368-1, EN 62368-1, FCC Part 15, EN 302 208, EN 300 328, EN 301 489-1/3/17/19/52
Benefits
The FXR90 is built to endure the toughest conditions, from extreme weather to daily wash-downs in industrial settings. Its dual IP65 and IP67 ratings ensure it remains dust, spray, and waterproof, maintaining high performance in any environment.
With a read rate exceeding 1,300 tags per second, the FXR90 offers unparalleled visibility and real-time data accuracy. Its rugged, sealed M12 connectors and high receiver sensitivity guarantee reliable operation even in challenging conditions.
The FXR90 integrates advanced wireless technologies, including Wi-Fi 6, Bluetooth 5.3, 5G, and GPS, for seamless configuration and management. Its built-in RFID antenna and multiple antenna port configurations allow flexible and efficient deployment across large facilities.
Related Products
The ID CPR30+ Desktop Reader is a proximity reader designed for contactless data exchange with ISO 15693 and ISO 14443-A/-B compliant transponders. It is compact, reliable, and compatible with NFC applications. With its NFC High Power Mode, it offers enhanced reading ranges and improved reliability, making it ideal for use in offices, workstations, or at the point of sale. The reader is form, fit, and function compatible with ID CPR30 and is qualified according to Zhaga Book 24, commonly used in the lighting industry. It is powered and connected to a computer or other equipment via the USB interface.
- Dimensions: 144 mm x 84 mm x 18 mm
- Weight: approximately 105 g
- Housing: Plastic (ASA) / Acrylic glass
- Color: white / black
- Protection class: IP42
- Operating frequency: 13.56 MHz
- Transmitting power: 100 mW / 300 mW
- Supply voltage: 5 V, USB Bus powered
- Current consumption: max. 150 mA / 220 mA
- Antenna: integrated
- Interface: USB Full-Speed (12 MBit/s)
- Indicators, optical: 2 LED (green / orange)
- Indicators, acoustic: Buzzer, integrated
- Supported transponders: ISO 15693, ISO 14443-A*/, ISO 14443-B
- Operation mode: Polling-Mode
- USB driver: Windows Server 2016 and 2019, Windows 10 and 11; 32 / 64 Bit
- Temperature range:
- Operation: -20 degree C up to +60 degree C
- Storage: -40 degree C up to +85 degree C
- Relative air humidity: max. 95% (non-condensing)
The ID ANT800/600-DA HF Loop Antenna is a versatile and high-performance antenna designed for use with HF readers. With a read range of up to 100 cm and a transmitting power of 8 W, this antenna is capable of delivering reliable and efficient RFID communication. Its easy setup, integrated dynamic antenna tuner, and IP65 protection class make it suitable for various applications.
- Dimensions: 852 mm x 620 mm x 40 mm
- Weight: approximately 2.5 kg
- Housing: Plastic ABS
- Color: Black
- Protection class: IP65
- Operating temperature range: -25 degree C up to +55 degree C
- Storage temperature range: -25 degree C up to +60 degree C
- Relative air humidity: 5% up to 95% (not condensing)
- Operating frequency: 13.56 MHz
- Max. transmitting power: 8 W
- Permitted transmitting power:
- EU (EN 300 330): 4 W
- USA (FCC Part 15): 2 W
- Canada (RSS-210): 2 W
- Read range: up to 100 cm*
- Antenna connection: 1 x SMA plug (50 ohm)
- Antenna connection cable: RG58, 50 ohm, approximately 3.6 m
The ID ANT.U290/290 and ID ANT.U580/290 are robust UHF RFID antennas designed for optimized reading performance. With circular polarization, these antennas allow for the identification of transponders in different orientations, enabling 3-dimensional identification in gate applications. They are suitable for both indoor and outdoor use, with a high protection class IP67 rating. These antennas have a modern and elegant design, and they are available in different dimensions and colors. They have TNC connectors and VESA connection for easy installation. The ID ANT.U580/290 has a 30° beam width, making it particularly suitable for vehicle identification and Free Flow Tolling systems.
- Dimensions (ID ANT.U290/290): 288 mm x 288 mm x 65 mm
- Dimensions (ID ANT.U580/290): 576 mm x 288 mm x 80 mm
- Housing: PC / Aluminium
- Color: Anthracite, translucent
- Weight (ID ANT.U290/290): 1,550 g
- Weight (ID ANT.U580/290): 3,850 g
- Protection class: IP67
- Gain (ID ANT.U290/290): Approx. 9 dBic
- Gain (ID ANT.U580/290): Approx. 11 dBic
- 3 dB beam width (ID ANT.U290/290): 65 x 65
- 3 dB beam width (ID ANT.U580/290): 30 x 65
- Polarization: Circular
- Antenna connection: TNC socket (50 ohm)
- Temperature range (ID ANT.U290/290): -25 degree C up to +55 degree C
- Temperature range (ID ANT.U580/290): Not specified
- Storage temperature range (ID ANT.U290/290): -25 degree C up to +80 degree C
- Tolerances: ±0.5 mm
The ID MAT Manual Antenna Tuner is a versatile and reliable device designed for manual tuning and retuning of HF Long Range Antennas operating at a frequency of 13.56 MHz. It allows for easy construction of customized single antennas using different sizes and shapes of antenna conductors such as aluminium bands or copper pipes. With individually switchable capacitors, the antenna can be tuned to its environment, ensuring optimal performance. The ID MAT.S-A variant also features an electronic switch to disconnect the antenna circuit, preventing coupling effects in complex antenna arrangements.
- Dimensions (w x h x d):
- ID MAT-B: 90 mm x 45 mm x 17 mm
2. ID MAT.S-A: 90 mm x 45 mm x 19 mm - Weight: approximately 35 g
- Operating frequency: 13.56 MHz
- Antenna conductor: Double-sided solder surface with hole for screw attachment (M3)
- Transmitting power: maximum 8 W
- Reader connection: SMA HF socket RG58
- Impedance: 50 ohm
- Tuning range inductivity: 0.6 – 2.3 microH
- Quality: 10 – 50
- Temperature range:
- Operation: -25 degree C up to +55 degree C
- Storage: -25 degree C up to +60 degree C
- Standard conformity:
- Vibration: EN 60068-2-6, 10 Hz to 150 Hz: 0.075 mm / 1 g
2. Shock: EN 60068-2-27, Acceleration: 30 g
The ID ANT.MUX.M4 is a 4 channel Multiplexer Module designed for switching between RFID antennas operating at a frequency of 13.56 MHz. It allows multiple single antennas and gate solutions to be operated with just one reader. The Multiplexer is controlled via the antenna cable connected to the reader, making installation easy and hassle-free. With non-wearing electronic switches and high switching speed, this Multiplexer ensures efficient and reliable communication between the reader and antennas.
- Dimensions: 137 mm x 77 mm x 15 mm
- Weight: approximately 80 g
- Operating frequency: 13.56 MHz
- Supply voltage: 12 – 24 V DC
- Power consumption: maximum 4.0 W
- Attenuation per channel: maximum 0.5 dB
- Max. perm. switching power: 8 W
- RF connections: 1x input (SMA jack), 4x output (SMA jack)
- RF switches: electronic switches (non-wearing) with switching speed < 1 ms
- Triggering reader: communication via RF input 1
- Signal indicator: 1 x LED per channel, 3 x LED (Run / HF / Communication)
- Temperature range: Operation: -25 degree C to +65 degree C (-13 F to +149 F), Storage: -40 degree C to +80 degree C (-40 F to +176 F)
- Standard conformity: EMC (EN 61000-6-3, EN 61000-6-2), Vibration (EN 60068-2-6, 10 Hz to 150 Hz: 0.075 mm / 1 g), Shock (EN 60068-2-27, Acceleration: 30 g)
The AT288N by ATID offers unparalleled efficiency in RFID data collection. With its advanced technology, this handheld reader empowers businesses to streamline their inventory management, asset tracking, and supply chain operations with precision and speed. Its ergonomic design ensures comfortable usage, while its robust build guarantees durability in various environments.
Elevate your RFID data collection capabilities with the AT288N by ATID. Engineered to excel in efficiency, this handheld reader revolutionizes inventory management, asset tracking, and supply chain operations. Its cutting-edge technology empowers businesses to capture data with unprecedented speed and accuracy, enhancing overall productivity and decision-making. Designed for user comfort and durability, the AT288N ensures seamless integration into diverse workflows, making it the ultimate solution for optimizing operational efficiency and gaining actionable insights.
- Supported protocols: UHF EPC Gen2, ISO / IEC 18000-6C, 6B, AEI (Rail)
- Connectivity: BT V2.1 + EDR / BLE V4.1
- Compatibility: Windows, Android & iOS Host
- Design: Compact & Handy design
- Drop: spec: 5m (5ft)
- IP65
- Reading Range: ~3M (According to Tag & Environment).
- Battery Life: a 3.7V 2,200mAh Lithium-Ion Battery (Rechargeable).
- Operating Temperature: -10degree C to 45degree C.
- Dimensions: 165mm x 75mm x 29mm
- Weight: 320 grams
